| Status | Active |
| Watts | 500W |
| Volts | 130V |
| Shape | T3 |
| Filament | C-8 |
| Base | Double Ended Recessed Single Contact |
| ANSI Base | R7s |
| Finish | Clear |
| CCT (Kelvin) | 2900K |
| Temperature | Warm White |
| CRI | 100 |
| Lumens | 9500L |
| Beam Spread | 360 |
| Dimmable | Non-Dimmable |
| Hours Rated | 1500 |
| Product Category | Double Ended Halogen |
| Lamp Type | Double Ended Halogen |
| Technology | Halogen |
| Watts | 500W |
| Volts | 130V |
| Amps | 3.846A |
| Filament | C-8 |
| CCT (Kelvin) | 2900K |
| Temperature | Warm White |
| CRI | 100 |
| Lumens | 9500L |
| Beam Spread | 360 |
| Dimmable | Non-Dimmable |
| Hours Rated | 1500 |
| Start Method | Probe Start |
| Operating Position | Universal |
| MOL | 4.69 |
| MOD | 0.38 |
| Shape | T3 |
| Base | Double Ended Recessed Single Contact |
| ANSI Base | R7s |
| Finish | Clear |
| Lensed | Lensed Lamp |
| Housing Color | None |
| Weight (lb.) | 0.02 |
| Safety Listing | Not Listed |
| Location Rating | Damp |
| California Prop 65 | Lead |
| RoHS Compliant | Yes |
| SDS Sheet | Halogen Double Ended or Pin Based Lamp |
| Each UPC | 045923019265 |
| Each Quantity | 1 |
| Each Length (in.) | 1.00 |
| Each Width (in.) | 1.00 |
| Each Height (in.) | 5.50 |
| Each Weight (lb.) | 0.03 |
| Each Cube (CuFt.) | 0.0032 |
| Pack Type | Box |
| Inner UPC | 20045923019269 |
| Inner Quantity | 12 |
| Inner Length (in.) | 3.90 |
| Inner Width (in.) | 5.60 |
| Inner Height (in.) | 6.00 |
| Inner Weight (lb.) | 0.40 |
| Inner Cube (CuFt.) | 0.0758 |
| Case UPC | 10045923019262 |
| Case Quantity | 480 |
| Case Length (in.) | 11.50 |
| Case Width (in.) | 13.00 |
| Case Height (in.) | 21.25 |
| Case Weight (lb.) | 21.10 |
| Case Cube (CuFt.) | 1.8385 |
